Stainless Steel Welded Wire Mesh With Different Hole Size in Sheet
Welded wire mesh is constructed with two orthogonal wires that are
joined together at their intersections using a resistance welding
process to form a grid. The line wires of the grid are guided
through the welder using a pattern board. The machine drops cross
wires into place and fuses them together to create the two
distinctive planes that form welded wire mesh.
Trim and Stub Options
We offers a variety of trim and stub options to suit your needs.
Contact one of our knowledgeable sales representatives if you’re
not sure which option is best for your project.
Trimmed: Minimum on all four sides approximately 1/16″-1/8″ long. Trimmed
flush (no stubs) must be specified when required.
Untrimmed Balanced Stubs: Equal stubs on opposite sides only. Stubs will not exceed opening
Balanced Stubs with Edge Wire: Equal stubs on opposite sides with welded edge wire. (Special
Untrimmed Random Stubs: Varies on all four sides. Results from shearing a larger sheet,
pieces will not be identical.
Trimme Untrimmed Balanced Balanced Stubs Random Untrimmed
Materials: Stainless steel,Carbon Steel,Iron Steel,Galvanized,PVC,etc.
|Specification List of Welded Wire Mesh|
|In inch||In metric unit(mm)|
|1/4" x 1/4"||6.4mm x 6.4mm||22,23,24|
|3/8" x 3/8"||10.6mm x 10.6mm||19,20,21,22|
|1/2" x 1/2"||12.7mm x 12.7mm||16,17,18,19,20,21,22,23|
|5/8" x 5/8"||16mm x 16mm||18,19,20,21,|
|3/4" x 3/4"||19.1mm x 19.1mm||16,17,18,19,20,21|
|1" x 1/2"||25.4mm x 12.7mm||16,17,18,19,20,21|
|1" x 1"||25.4mmX25.4mm||16,17,18,19,20,21|
|1-1/2" x 1-1/2"||38mm x 38mm||14,15,16,17,18,19|
|1" x 2"||25.4mm x 50.8mm||14,15,16|
|2" x 2"||50.8mm x 50.8mm||12,13,14,15,16|
|2" x 3"||50mmx70mm||2.0mm,2.5mm,1.65mm|
|3" x 3"||75mmx75mm||2.67mm,2.41mm,2.11mm,1.83mm,1.65mm|
|2" x 4"||50mmx100mm||2.11mm,2.5mm|
|4" x 4"||100mmx100mm||2.0mm,2.5mm|
1, Standard roll length: 30m; width: 0.5m to 1.8m
2, Special sizes available at request
3, Packing: in waterproof paper in rolls. Custom packing available
