| Categories | Semi Automatic Terminal Crimping Machine |
|---|---|
| Place of Origin: | Guangdong, China |
| Brand Name: | Yihan |
| Model Number: | YH-DT4.0T |
| Usage: | Crimping |
| Product name: | Copper belt wire connector crimping machine |
| Weight: | 105kg |
| Pressing capicity: | 4000KG |
| Power: | 1500W |
| Crimping stroke: | 30mm |
| Work efficiency: | 2000 times/hour |
| Dimension: | 500*380*580mm |
| Application copper strip: | 1.0mm,1.5mm,2.0mm,4.0mm,6.0mm |
| product name: | Connector Connecting Copper Belt Connect Wire Cable Crimping Machine |
| Feeding method: | Stepper motor automatic feeding |
| Packaging Details: | wooden package |
| Port: | shenzhen/guangzhou/zhejiang/shanghai/ningbo/jiangsu |
| Supply Ability: | 1000 Set/Sets per Month |
| Price: | $2,200.00/sets 1-4 sets |
| MOQ: | 1 set |
| Company Info. |
| Yihan (shenzhen) Automation Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
1: This machine is designed for the wire that needs riveting, pressing the riveting and connecting the wire to replace the traditional welding method.
2: Using special continuous copper strip terminal, the material is
cut, formed, pressed once, quickly and without waste, saving cost.
3: The copper belt is treated by special grain, and the endurance
is very strong after riveting.
4: Scope of application: the connection between the xenon lamp and
the resistor, the connection between the slide switch and the wire, the connection between the high temperature heating elements,
and the connection between the thermosensitive elements.
5:Stepper motor electric feeding, feeding length is more accurate,
debugging is more convenient.
1. The connection between the neon lamp and the resistor, the connection between the LED and the wire
2. The slide switch is connected to the wire (replaces hook
welding)
3. Connection of high temperature heating element
4. Connection of sensitive components (such as reed switch,
thermostat fuse)
5. Connection between transformer tap and wire
| Product Name | Electric feed copper tape splicing Machine | |
| Model | YH-DT4.0T | YH-DT3.0T |
| Feeding method | Stepper motor automatic feeding | |
| Power Supply | AC220V 50/60HZ | |
| Pressing capicity | 4000KG | 3000KG |
| Stroke Length | 30mm | 23mm |
| Work efficiency | 2000 times/hour | |
| Motor Power | 1500W | 1100W |
| Height adjustment | 8MM | 8MM |
| Dimension | 500*380*580mm | 400*290*450mm |
| Weight | 105KG | 45KG |
|
